ARC Welders (MMA)

MAXUS ARC 400 PRO

The Maxus Arc 400 Pro is a professional-grade arc welding machine for fabrication and other structural steel work. The machine has excellent dynamic features, ensuring a high open-circuit voltage and strong energy compensation.

Technical Specifications

Input Voltage 3P 415V Input
Current Range 40-400A Range
System Feature 20.5 Kg Weight
System Feature Heavy Fabrication

Machine Specifications

Model Range Maxus ARC 400 PRO
Input Voltage 415V 3ph 50/60Hz
Rated Input Capacity 26A
Open Circuit Voltage 69V
Welding Current 40~400A
Duty Cycle (40° C) 60%@400A
Load Voltage 36V
Insulation Class H
Protection Class IP21S
Dimensions (L*W*H) 471*252*468 mm
Weight 20.5 Kg
Socket Type Lug Type

Key Features

  • Suitable for welding stainless steel, alloy steel, and other non-ferrous metals
  • Ideal for high-altitude operations
  • Stable arc performance
  • Suitable for multiple welding electrode types
  • Compact design for convenient installation

Customer Benefits

  • Reduces downtime
  • Durable machine performance
  • Lowers operating costs
  • Enables smooth welding
  • 2-year warranty

Applications

Maintenance and repair operations Metal fabrication and assembly Shipbuilding and marine fabrication Agricultural machinery Oil and gas equipment
